Axiom Supply Polaris Ranger Front Lifetime Warranty Wheel Bearing 400 / 500 / 570 / 700 / 800 Midsize 2006 - 2025

Bearing Features:

• Oversized Heavy-Duty Internals: Built to handle extreme loads without flexing or premature failure.

• Performance Bearing Geometry: Engineered for increased strength, consistent load control, and reduced unwanted hub movement.

• Reduced Hub Deflection: Helps improve braking performance, steering accuracy, and overall vehicle stability.

• Built for Hard-Use Polaris Machines: Engineered to withstand oversized tires, heavy payloads, mud, water, hard impacts, and demanding off-road use.

• Lifetime Warranty Coverage: Designed to be the last wheel bearing your Polaris will ever need.

Fitment

Polaris Ranger – FRONT

This bearing is primarily used as a front wheel bearing on applicable Polaris Ranger midsize and strut-style platforms.

Position: Front Driver or Passenger Side

Ranger 400

Fits applicable:

• Ranger 400

• Ranger 400 Midsize

Bearing Position: Front Left or Front Right

Ranger 500

Fits applicable:

• Ranger 500

• Ranger 500 EFI

• Ranger 500 Midsize

• Ranger Crew 500

• Ranger 500 Crew Midsize

Bearing Position: Front Left or Front Right

Ranger 570

Fits applicable models including:

• Ranger 570

• Ranger 570 EPS

• Ranger 570 Midsize

• Ranger 570 Full Size

• Ranger Crew 570

• Ranger Crew 570 EPS

• Ranger Crew 570 Full Size

Bearing Position: Front Left or Front Right

Applicable Ranger 570 models use this 35mm bearing in the front and commonly use the Axiom 40mm AXRZBR40 bearing in the rear.

Ranger 700

Fits select:

• Ranger 700

• Ranger Crew 700

• Ranger 700 6x6

Bearing Position: Front Left or Front Right

Ranger 800 Midsize

Fits applicable:

• Ranger 800 Midsize

• Ranger 800 Midsize EPS

Bearing Position: Front Left or Front Right

Important: This applies specifically to applicable Ranger 800 Midsize models. Many larger/full-size Ranger 800 applications use the larger Axiom 44mm bearing in the front.

Ranger ETX

Fits applicable:

• Ranger ETX

• Ranger ETX EPS

Bearing Position: Front Left or Front Right

Ranger EV

Fits select:

• Ranger EV

• Ranger EV EPS

Bearing Position: Front Left or Front Right

Ranger Front vs. Rear Bearing Guide

Polaris uses different wheel bearing sizes depending on the Ranger chassis and axle position.

Midsize / Strut-Style Ranger Applications

Front:
Axiom AXRZBR35
35mm ID × 64mm OD × 37mm Wide

Rear:
Axiom AXRZBR40
40mm ID × 74mm OD × 40mm Wide

This configuration is commonly found on applicable:

• Ranger 400

• Ranger 500

• Ranger 570

• Ranger Crew 570

• Ranger ETX

• Ranger EV

• Ranger 700

• Ranger 800 Midsize

Larger / Full-Size / XP Ranger Applications

Many larger Ranger platforms do not use AXRZBR35 in the front.

Instead, applicable models commonly use:

Front:
Axiom 44mm Lifetime Warranty Wheel Bearing
44mm ID × 72mm OD × 33mm Wide

Rear:
Axiom AXRZBR40
40mm ID × 74mm OD × 40mm Wide

Common examples include applicable:

• Ranger 800 Full-Size

• Ranger XP 800

• Ranger XP 570

• Ranger XP 900

• Ranger Crew XP 900

• Ranger 1000

• Ranger Crew 1000

• Ranger XP 1000

• Ranger Crew XP 1000

Shop the Axiom Supply 44mm Polaris Lifetime Warranty Wheel Bearing Here

Polaris Sportsman – Primarily FRONT

AXRZBR35 is also used as a front wheel bearing on a wide range of applicable Polaris Sportsman models.

Fits select years and configurations of:

• Sportsman 300

• Sportsman 400

• Sportsman 450

• Sportsman 500

• Sportsman 570

• Sportsman 600

• Sportsman 700

• Sportsman 800

• Sportsman Touring 500

• Sportsman Touring 570

• Sportsman Touring 800

• Sportsman X2 500

• Sportsman X2 570

• Sportsman X2 700

• Sportsman X2 800

• Sportsman 6x6 570

• Sportsman 6x6 800

Typical Position: Front Left or Front Right

Many applicable Sportsman models using the 35mm bearing in the front use the 40mm bearing in the rear.

Typical Sportsman Bearing Configuration

Front: AXRZBR35 – 35 × 64 × 37mm
Rear: AXRZBR40 – 40 × 74 × 40mm

Important: Certain older Sportsman models use different bearing configurations, and some historical applications use the 35mm bearing in the rear. Verify OE number before ordering.

Polaris ACE

Fits select:

• ACE 325

• ACE 500

• ACE 570

• ACE 900

Typical Position: Front Left or Front Right

Applicable ACE platforms commonly pair:

Front: AXRZBR35 – 35mm bearing
Rear: AXRZBR40 – 40mm bearing

Polaris Hawkeye

Fits select:

• Hawkeye 300

• Hawkeye 325

• Hawkeye 400

Position varies by year and configuration. Verify OE number before ordering.

Additional Polaris Applications

AXRZBR35 also fits select years and configurations of Polaris:

• Scrambler

• Magnum

• Trail Blazer

• Trail Boss

• ATP

• Worker

• Xplorer

• Farmhand

• Select older Polaris ATV and utility models

Important: Bearing position varies on these older applications. Verify OE number or dimensions before ordering.

Details:

The Axiom Supply AXRZBR35 Lifetime Warranty Wheel Bearing is designed as a heavy-duty replacement for applicable Polaris wheel bearing applications.

Replaces / Interchanges:

Polaris 3514634
Polaris 3514342

Polaris Heavy-Duty OE Reference:

3515088

Bearing Dimensions:

35mm ID × 64mm OD × 37mm Wide

Primary Ranger Position:

Front Driver or Passenger Side

Need the Matching Rear Ranger Bearing?

Many Polaris Ranger models using AXRZBR35 in the front use the Axiom AXRZBR40 in the rear.

AXRZBR35 – Front
35mm ID × 64mm OD × 37mm Wide

AXRZBR40 – Rear
40mm ID × 74mm OD × 40mm Wide

AXRZBR40 replaces applicable Polaris OE numbers:

• 3514635

• 3514917

• 3585502

For applicable Ranger midsize applications, this gives customers a simple:

35mm Front / 40mm Rear

bearing combination.

Have a Larger Ranger or Ranger XP?

Many larger Ranger applications use the 44mm Axiom Lifetime Warranty Bearing in the front instead of AXRZBR35.

Shop the Axiom Supply 44mm Polaris Lifetime Warranty Wheel Bearing Here

Typical larger Ranger configuration:

44mm Front / 40mm Rear

Important Fitment Note:

Polaris has used multiple wheel bearing sizes across Ranger, Sportsman, ACE, and other platforms.

Do not assume front and rear wheel bearings are the same size.

Before ordering AXRZBR35, verify that your vehicle uses one of the following:

• Polaris OE 3514634

• Polaris OE 3514342

• Polaris HD OE 3515088

• Bearing dimensions of 35mm ID × 64mm OD × 37mm wide

Certain newer Polaris applications may use updated OE numbers even where bearing dimensions appear similar. Compatibility should be verified by OE interchange rather than dimensions alone.

For additional fitment assistance, please email Axiom Supply before ordering.

Installation Instructions Here

Description:

The Axiom Supply AXRZBR35 Polaris Lifetime Warranty Wheel Bearing is built for Ranger and Polaris ATV owners who refuse to accept weak factory components.

Front wheel bearings take a tremendous amount of abuse. Steering loads, oversized tires, hard impacts, mud, water, heavy payloads, and aggressive riding all place additional stress on the wheel-end assembly.

Axiom Supply engineered AXRZBR35 as a true heavy-duty replacement.

Built with oversized, high-strength internals and performance-focused bearing geometry, this bearing is designed to control wheel and hub movement while maintaining smooth, consistent rotation under load.

Reduced hub deflection helps provide sharper steering response, more consistent braking, and improved wheel stability while minimizing premature wear throughout the front suspension and wheel-end assembly.

Whether your Ranger spends its life working, hunting, farming, or riding trails—or your Sportsman spends its weekends buried in mud—AXRZBR35 is built for the conditions that expose weaknesses in ordinary replacement bearings.

This isn't intended to be another disposable replacement part. It's a long-term upgrade.

Axiom Supply backs AXRZBR35 with our True No-Nonsense Lifetime Replacement Warranty.

If you're tired of replacing wheel bearings, this is designed to be the last one you'll install.

WHY AXIOM SUPPLY

• Oversized heavy-duty internal components

• Designed for high-load UTV and ATV applications

• Built for oversized tires and modified machines

• Helps reduce excessive hub movement

• Improves steering and braking consistency

• Built for mud, water, hard impacts, and harsh off-road conditions

• Direct replacement for applicable Polaris OE bearing dimensions

• Backed by a true Lifetime Replacement Warranty

• Proven under real riding and working conditions—not just lab testing

Includes:

(1) Axiom Supply AXRZBR35 Wheel Bearing

The Axiom No-Nonsense Lifetime Warranty

Our suspension, and wheel-bearing components are warrantied for life to the original purchaser against any manufacturer defects, premature wear, or breakage.

Push it to the limit—we don't care.
If the part lets you down, we will make it up to you!
