Bilstein B8 5160 Series stock-mount remote reservoir shocks feature the company's industry-leading monotube design, with a reservoir mounting configuration specifically designed for each application. Their unique digressive valving system instantly produces full damping capabilities for serious off-road performance and control. The remote reservoir dramatically increases shock oil capacity for excellent heat dissipation and damping sensitivity. A floating dividing piston is located in the reservoir of these shocks to offer increased wheel travel and more shaft movement. Special swivel banjo fittings on the reservoir hose allow for 360 degrees of rotation. Bilstein's exclusive Triple-C Technology finish provides the B8 5160 Series shocks with lasting great looks and easy care.
Bilstein B8 5160 25-254785
Collapsed Length (IN) - 13.86
Extended Length (IN) - 18.52
Upper Mount Type - Crossbar
Lower Mount Type - Clevis
Bilstein B8 5160 25-196481
Collapsed Length (IN) - 16.54
Extended Length (IN) - 28.09
Upper Mount Type - Eye 14.4mm
Lower Mount Type - Eye 14.4mm
Fits 2011-2023 GM 2500/3500 Trucks
