Bilstein B8 5160 Series stock-mount remote reservoir shocks feature the company's industry-leading monotube design, with a reservoir mounting configuration specifically designed for each application. Their unique digressive valving system instantly produces full damping capabilities for serious off-road performance and control. The remote reservoir dramatically increases shock oil capacity for excellent heat dissipation and damping sensitivity. A floating dividing piston is located in the reservoir of these shocks to offer increased wheel travel and more shaft movement. Special swivel banjo fittings on the reservoir hose allow for 360 degrees of rotation. Bilstein's exclusive Triple-C Technology finish provides the B8 5160 Series shocks with lasting great looks and easy care.
Bilstein B8 5160 25-218190
Collapsed Length (IN) - 15.57
Extended Length (IN) - 24.23
Upper Mount Type - Bar Pin
Lower Mount Type - Clevis
Bilstein B8 5160 25-218206
Collapsed Length (IN) - 18.17
Extended Length (IN) - 31.26
Upper Mount Type - Eye 14.4mm
Lower Mount Type - Eye 14.4mm
